Guangxi Ligong Machinery Co.,Ltd
1. Patent gearbox and torque converter: Save 25% oil consumption.
2. Split structure gearbox and torque converter: Decrease 30% working temperature which can ensure a longer service life of the hydraulic components.
3. Three-stage air filtration technology: Effectively protect engine to prolong 30% engine life.
4. Double High and Low Walking Speed System: National patent system
QUOTATION LIST | |||
Overall Performance/Models整体型号 | Unit | LC938 | |
General Machine Performance | Operating weight | kg | 5800 |
Length | mm | 6600 | |
Width | mm | 2050 | |
Height | mm | 2860 | |
Wheel base | mm | 2780 | |
Wheel track | mm | 1670 | |
Total cycle time | s | 9 | |
Tire size | size | 16/70-20 | |
Max.travelling speed | km/h | 35 | |
Bucket Performance | Loading weight | kg | 2000 |
Standard bucket capacity | m3 | 1 | |
Possible Bucket capacity | m3 | 0.7-1.5 | |
Bucket width | mm | 2000 | |
Dumping height | mm | 3600 | |
Dumping reach | mm | 950 | |
Max. lifting height | mm | 5300 | |
Transmission Performance | Transmission type | name | Automatic |
Control type | kw | Hydraulic | |
Axle | type | big wheel hub reduction | |
Engine Performance | Brand | name | YUCHAI 4102 Turbo |
Power | kw/ rpm | 78 | |
Rotate speed | rpm | 2400 | |
Number of cylinders | unit | 4 |
