Product Details

Guangxi Ligong Machinery Co.,Ltd

LC939

1. Patent gearbox and torque converter: Save 25% oil consumption.

2. Split structure gearbox and torque converter: Decrease 30% working temperature which can ensure a longer service life of the hydraulic components.

3. Three-stage air filtration technology: Effectively protect engine to prolong 30% engine life.

4. Double High and Low Walking Speed System: National patent system

QUOTATION LIST
Overall Performance/Models整体型号		Unit	LC939
General Machine Performance	Operating weight	kg	6000
	Length	mm	6740
	Width	mm	2050
	Height	mm	2960
	Wheel base	mm	2810
	Wheel track	mm	1700
	Total cycle time	s	9
	Tire size	size	16/70-24
	Max.travelling speed	km/h	35
Bucket Performance	Loading weight	kg	2500
	Standard bucket capacity	m3	1.1
	Possible Bucket capacity	m3	0.7-1.5
	Bucket width	mm	2200
	Dumping height	mm	3600
	Dumping reach	mm	800
	Max. lifting height	mm	5400
Transmission Performance	Transmission type	name	Automatic
	Control type	kw	Hydraulic
	Axle	type	big wheel hub reduction
Engine Performance	Brand	name	YUCHAI 4105 Turbo
	Power	kw/ rpm	85
	Rotate speed	rpm	2400
	Number of cylinders	unit	4
