Product Details

Guangxi Ligong Machinery Co.,Ltd

LC22EU1

1.The computer optimization design has the function of high level automatic leveling and the aperation

efficiency is improved significantly.

2.The gearbox is designed and manufactured by our company. It is rugged and durable The gear ratio

matches reasonably and reduces power consumption.

3.Load sensing is full hydraulic priority,stable,reliable and energy saving.

4.The bucket pin has a dust proof apron, which prolongs the service life of the pin shaft and the bushing.

Overall performance	Unit	Value	Pictures
Excavator model		LC22E
Engine Model		Yanmar 3TNV70-SSY
Rated Power	KW	10
Rated Speed	r/min	2200
Working Pressure of Hydraulic Pump	mpa	20
Maximum walking speed	km/h	4.7/9.6
Rotary speed	rpm	11.5
Max Climb Capability	°	35
Bucket digging force	KN	20
Weight	kg	1780
Max ecavation depth	mm	2452
Max ecavation height	mm	3926
Max unloading height	mm	2652
Max vertical excavation depth	mm	1738
Max lifting heiht of bulldozer	mm	236
Max excavation depth of bulldozer	mm	161
Standard buket size(L*W)	mm	550*450
Standard buket capacity	m³	0.05
Profile size	mm	3800×1050-1300×2345
Optional attachments
