| Model | CPC(D)30 | |||
| Characteristics | Fuel type | Diesel | ||
| Load capacity | kg | 3000 | ||
| Load center | mm | 500 | ||
| Lift height | mm | 3000 | ||
| free lift height | mm | 145 | ||
| Fork dimension | mm | 1070×125×45 | ||
| Mast tilting angle | Deg | 6/12 | ||
| Min.turning radius | mm | 2400 | ||
| Min. Groud clearance | Mast | mm | 135 | |
| Frame | mm | 140 | ||
| Overhead guard height | mm | 2165 | ||
| Front overhang | mm | 490 | ||
| Performance | Max travel speed | km/h | 20 | |
| Max lift speed | mm/s | 480 | ||
| Max.towing force(full load) | KN | 20 | ||
| Max. gradeability | % | 20 | ||
| Dimensions | Total length with fork | mm | 3770 | |
| Total length without fork | mm | 2700 | ||
| Total width | mm | 1225 | ||
| Mast extended height | mm | 4265 | ||
| Mast lowered height | mm | 2060 | ||
| Chassis | Tyres Front | 28x9-15-12PR | ||
| Type Rear | 6.50-10-10PR | |||
| Wheelbase | mm | 1700 | ||
| Tread | mm | 1000/970 | ||
| Service weight | Kg | 4350 | ||
| Drive | Battery | V/Ah | 12/80 | |
| Motor | Model | Xinchai 490 | ||
| Rated output | kw/r.p.m | 40/2650 | ||
| Rated torque | Nm/r.p.m | 162/1900 | ||
| Cylinders | 4 | |||
| Displacement | L | 2.67 | ||
| Fuel tank capacity | L | 70 | ||
| Transmission | Machenical | |||
