Product Details

Guangxi Ligong Machinery Co.,Ltd

CPC(D)50

Main Features

1. The forklift door frame is made of 20 manganese silicon channel steel to ensure the hardness of the door frame and prolong the service life of the entire door frame.
2. The forks are forged forks to ensure the strength of the fork and improve the safety factor.
3. The intelligent electronic control system makes the vehicle control more refined and reduces the operating cost of the whole machine.

>

<

Detail Information

Model				CPC(D)50
Characteristics	Fuel type		Diesel
	Load capacity		kg	5000
	Load center		mm	600
	Lift height		mm	3000
	free lift height		mm	130
	Fork dimension		mm	1220×150×60
	Mast tilting angle		Deg	6/12
	Min.turning radius		mm	3330
	Min. Groud clearance	Mast	mm	200
		Frame	mm	240
	Overhead guard height		mm	2410
	Front overhang		mm	550
Performance	Max travel speed		km/h	26
	Max lift speed		mm/s	380
	Max.towing force(full load)		KN	24
	Max. gradeability		%	20
Dimensions	Total length with fork		mm	4675
	Total length without fork		mm	3455
	Total width		mm	1995
	Mast extended height		mm	4429
	Mast lowered height		mm	2510
Chassis	Tyres Front		8.25-15-14PR
	Type Rear		8.25-15-14PR
	Wheelbase		mm
	Tread		mm	1470/1700
	Service weight		Kg	8000
Drive	Battery		V/Ah	12/80
	Motor	Model	全柴4C6/锡柴CA4110
		Rated output	kw/r.p.m	85/2200
		Rated torque	Nm/r.p.m	450/1400-1800
		Cylinders	4
		Displacement	L	5.785
	Fuel tank capacity		L	70
	Transmission		Machenical
