Guangxi Ligong Machinery Co.,Ltd

CPCD70

Main Features

1. The forklift door frame is made of 20 manganese silicon channel steel to ensure the hardness of the door frame and prolong the service life of the entire door frame.
2. The forks are forged forks to ensure the strength of the fork and improve the safety factor.
3. The intelligent electronic control system makes the vehicle control more refined and reduces the operating cost of the whole machine.

>

<

Detail Information

Model				CPCD70
Characteristics	Fuel type		Diesel
	Load capacity		kg	7000
	Load center		mm	600
	Lift height		mm	3000
	free lift height		mm	160
	Fork dimension		mm	1220×150×65
	Mast tilting angle		Deg	6/12
	Min.turning radius		mm	3450
	Min. Groud clearance	Mast	mm	240
		Frame	mm	350
	Overhead guard height		mm	2500
	Front overhang		mm	650
Performance	Max travel speed		km/h	24
	Max lift speed		mm/s	350
	Max.towing force(full load)		KN	25
	Max. gradeability		%	20
Dimensions	Total length with fork		mm	4810
	Total length without fork		mm	3592
	Total width		mm	1995
	Mast extended height		mm	4419
	Mast lowered height		mm	2519
Chassis	Tyres Front		8.25-15-14PR
	Type Rear		8.25-15-14PR
	Wheelbase		mm
	Tread		mm	1470/1700
	Service weight		Kg	9350
Drive	Battery		V/Ah	24/80
	Motor	Model	锡柴CA6110
		Rated output	kw/r.p.m	63.9/2300
		Rated torque	Nm/r.p.m	285/1700
		Cylinders	4
		Displacement	L	4.996
	Fuel tank capacity		L	80
	Transmission		Hydraulic
