Guangxi Ligong Machinery Co.,Ltd

Product Details

Guangxi Ligong Machinery Co.,Ltd

CPCD100

Main Features

1. The forklift door frame is made of 20 manganese silicon channel steel to ensure the hardness of the door frame and prolong the service life of the entire door frame.
2. The forks are forged forks to ensure the strength of the fork and improve the safety factor.
3. The intelligent electronic control system makes the vehicle control more refined and reduces the operating cost of the whole machine.

>

<

Detail Information

Model				CPCD100
Characteristics	Fuel type		Diesel
	Load capacity		kg	10000
	Load center		mm	600
	Lift height		mm	3000
	free lift height		mm	200
	Fork dimension		mm	1500×160×80
	Mast tilting angle		Deg	6/12
	Min.turning radius		mm	4050
	Min. Groud clearance	Mast	mm	240
		Frame	mm	350
	Overhead guard height		mm	2560
	Front overhang		mm	728
Performance	Max travel speed		km/h	25
	Max lift speed		mm/s	340
	Max.towing force(full load)		KN	28.5
	Max. gradeability		%	20
Dimensions	Total length with fork		mm	5750
	Total length without fork		mm	4250
	Total width		mm	2245
	Mast extended height		mm	4420
	Mast lowered height		mm	2850
Chassis	Tyres Front		4×900-20-14PR
	Type Rear		2×900-20-14PR
	Wheelbase		mm	2500
	Tread		mm	1600/1700
	Service weight		Kg	12900
Drive	Battery		V/Ah	24/80
	Motor	Model	锡柴CA6110
		Rated output	kw/r.p.m	86/2200
		Rated torque	Nm/r.p.m	470/1100-1700
		Cylinders	4
		Displacement	L	3.76
	Fuel tank capacity		L	90
	Transmission		Hydraulic
