CPD25 Electric Forklift-Forklift-Guangxi Ligong Machinery Co.,Ltd

Model			CPD25
Power type			Battery
Rated load		KG	2500
Load center distance		mm	500
Driving type			Seat
Length	With fork L1	mm	3380
	Without fork L2		2310
Whole Width B			1150
Height	Height no lifting frame H1		2000
	Top frame height H2		2145
	Max Height working H3		3995
Distance from seat to top light L3			1020
Wheel base L4			1515
Front overhang Y			483
Back overhang L5			400
Front wheel tread R			970
Back wheel tread P			950
Min Floor clearance F			135
Max lifting height H			3000
Free lifting height H4			170
Fork changing S			1024/200
Min Turning radius WA			2050
Min Right angle aisle width RA			3760
Frame angle a/β		（°）	6°/12°
Max lifting speed without goods		mm/s	380
Max lifting speed with full goods			280
Max speed without goods		Km/h	15
Max speed with full goods			14
Max climbing angle		％	≤15
Whole machine weight		Kg	4200
Driving Wheel			2x/2
Tyre model			Solid tyre
Front Tyre			7.00-12
Rear Tyre			18x7-8
Hand Brake			Hydraulic Pedal
Brake type			M-Hand
Battery Volt/ capacity		V/Ah	48/500
Driving motor power		Kw	11.0AC
pump power			12.0AC
